उत्पाद विवरण
उत्पत्ति के प्लेस: चीन
ब्रांड नाम: TOM
प्रमाणन: CE
मॉडल संख्या: मशीन
दस्तावेज़: उत्पाद पुस्तिका पीडीएफ
भुगतान और शिपिंग शर्तें
Main features:
1. Servo driven tracking and positioning filing, the whole machine is driven by one screw, filling and bottle moving are carried out synchronously, with fast speed and high precision.
2. Flow meter filling has multi-level material level detection, which can compensate the fling volume according to the liquid level height.
3. The material box has a pressurization mode. When the remaining material in the material box is insufficient, constant pressure filing can be performed even at different liquid levels.
4. Negative ion air blowing bottle, fine dust falls off without static electricity, vacuum extraction, remove dust.
5. The weighted stability system has been upgraded, and the operation is vibration-free, safe and reliable.
6. Equipped with complete machine lubrication system with automatic adjustment of lubrication time
7. It has a wide range of applications. There is no need to change the mold when changing specifications. The parts that need to be adjusted are marked with scales, which is convenient and quick.
8. Use world-renowned electrical appliances to ensure the durability of the equipment.
| Size range: | Diameter 20-60mm |
| Label height: | (30-90) mm, length: (40-140) mm |
| Production capacity: | ≤ 12000 bottles/hour |
| Labeling accuracy: | ± 1mm |
Filling specification: 100-1000ml
Production capacity: 4000-8000BPH
Scan the QR code to watch the video
Filling accuracy:±0.5%
Number of filling and washing heads: 8/10 washing heads, 8/10 filling heads
Suitable for filling shampoo, shower gel, hand soap, laundry detergent, dishwashing liquid and other materials.
Main configuration:
1. The whole machine has compact structure, simple transmission, long service life of parts, convenient
maintenance, few wearing parts and low operating noise;
2. High filling measurement accuracy, extremely fast filling speed, no dripping, etc.;
3. The machine has beautiful and elegant appearance, does not pollute the environment, and meets GMP standards;
Main parameters:
| Power supply: | AC380V, 50/60HZ |
| Whole line power : | About 48KW |
| Air pressure: | (0.6-0.7) MPa, dry, clean and stable gas source, single line gas consumption of about 0.9m ³/ min |
